Mild Steel Maschio Gaspardo Nina Seed Drill, For Agriculture, Size: 15 X 12 Inch

The model NINA features seed distribution by gravity. It is simple to use, reliable, sturdily built and requires very little maintenance. Furthermore it improves yield and no labour involved. This model is suitable for 60 to 100 HP tractors.

• Conventional mechanical seed drill
• Three point hitch, cat. II
• Fine and large dosing rollers combined for small and large seeds
• Infinite gearshift with 3 oil-cooled cams
• Wheels 6.50-15 with mud scrapers
• Suffolk coulters arranged in 3 ranks
• Suffolks replacement removing just one bolt
• Hopper capacity: NINA 250 410 Lt; NINA 300 500Lt
• Tractor hydraulic distributors required: at least 1
• Calibration and emptying tray
• Anti clogging suffolks protection
• Mechanical centralized coulters pressure adjustment
• Seed box level indicator
• Single transmission
• Excluding seed hopper agitator
• Half machine shut-off
• Lighting kit (disassembled)
• Row marker (not included)
• Seed covering harrow not included
• Fast depth adjustmentSeeding depth can be quickly adjusted through a mechanical or hydraulic system acting on sowing bar angle.
• Seeding unitThree options are available to make drill machine suited to work on a wide range of soil conditions.SUFFOLK COULTER. Suitable for ground cultivated in the traditional way and with little stubble, even when the soil is very compact and stony. Positioning in well-spaced rows to increase the distance between planting units. Expendable components quickly replaced as they are screwed, not welded.

  SINGLE DISC. Suitable for all types of soil, even when there is a lot of stubble. Constant control of the planting depth by means of an adjustable limiter or rubber wheel. The light pressure exercised on the seed encourages rapid germination.



  COREX DISC. Suitable for loose soil, even when there is a lot of stubble. The planting depth is regulated by means of an adjustable rubber wheel which exercises a slight pressure on the seed and encourages the germination process. The particular rounded shape of the two discs creates a planting furrow and prevents sinking or the soil from being moved to an excessive extent.

• GASPARDO gearbox – Easy and precise
  • Our 3 cam transmission design allows us to acquire maximum accuracy versus many competitors that have a two cam design.
  • Calibration is very time saving using our one handle lever to set the rate.
  • All of our cams and bearings on the gearbox run in an oilbath so that you do not have to worry about greasing them.
  • Multipurpose seed distributorDistribution unit has a very simple design and can be adapted to many different crops. Passing from large to smaller seeds is easy as excluding larger seeds ring. Adjustable spring feeler is very gentle with seed and preserves its viability for the best success of planting operation.
